SteerCATH
Guiding Catheters
Accurately Mentor Your Next Treatment Quickly Access Indicated Anatomy with the Steerable Catheter SteerCATH improves access to hard-to-reach sites with a wide variety of applications within the human vascula
Inner Diameter | 6.5F/ 7F / 8.5F | |
Usable Lenght | 45, 55, 90cm | |
Deflection Lenght | 9, 17, 22mm |
Detailed specifications
SteerCATHⓇ catheter is specifically designed to navigate complex and tortuous vascular structures for minimally invasive surgery with a physician-controlled mechanism. The device is guided by the clinician using the handle (proximal tip), optimising the response of the steerable portion of the catheter (tip) to provide precise control and torque response. It gives the physician the ability to guide catheters to a target location in the body. The SteerCath has multiple steering options, including unidirectional steering, bidirectional steering (bidirectional catheters), four-directional steering and multi-directional steering (commonly referred to as multi-directional catheters or multi-plane deflection).
We develop and manufacture standard or customized configurations of steerable catheter delivery systems to meet your device needs. From concept to manufacturing, we offer full-service steerable catheter production.
ADVANTAGES
- Eliminates the need to change directives to reach the desired position.
- Conformability.
- Curve retention.
- Radiopaque type.
- Hydrophobic coated.
- Up to 180 degrees Control.
- Precise deflection using the self-locking rotating knob allows you to maintain control of the full procedure.
- Adjustable Tip Deflection.
- Make certain kink resistance.
- Torque control.
- Our steerable configurations are fully customizable.
- Standard handles in 1-way and 2-way designs.
- Customized handles for multidirectional devices.
- Customized bend radius and deflection angle, including one-way, two-way, and multiplanar deflection.
Ture, from the periphery to the intracardiac.
Inner Diameter | 6.5F/ 7F / 8.5F | |
Usable Lenght | 45, 55, 90cm | |
Deflection Lenght | 9, 17, 22mm |
Order Number | Deflection Lenght | Catheter Inner Diameter | Catheter Lenght |
CR1065 | 9 mm | 6.5 Fr | 45 cm |
CR1066 | 9 mm | 7.0 Fr | 45 cm |
CR1067 | 9 mm | 8.5 Fr | 45 cm |
CR1068 | 9 mm | 6.5 Fr | 55 cm |
CR1069 | 9 mm | 7.0 Fr | 55 cm |
CR1070 | 9 mm | 8.5 Fr | 55 cm |
CR1071 | 9 mm | 6.5 Fr | 90 cm |
CR1072 | 9 mm | 7.0 Fr | 90 cm |
CR1073 | 9 mm | 8.5 Fr | 90 cm |
CR1074 | 17 mm | 6.5 Fr | 45 cm |
CR1075 | 17 mm | 7.0 Fr | 45 cm |
CR1076 | 17 mm | 8.5 Fr | 45 cm |
CR1077 | 17 mm | 6.5 Fr | 55 cm |
CR1078 | 17 mm | 7.0 Fr | 55 cm |
CR1079 | 17 mm | 8.5 Fr | 55 cm |
CR1080 | 17 mm | 6.5 Fr | 90 cm |
CR1081 | 17 mm | 7.0 Fr | 90 cm |
CR1082 | 17 mm | 8.5 Fr | 90 cm |
CR1083 | 22 mm | 6.5 Fr | 45 cm |
CR1084 | 22 mm | 7.0 Fr | 45 cm |
CR1085 | 22 mm | 8.5 Fr | 45 cm |
CR1086 | 22 mm | 6.5 Fr | 55 cm |
CR1087 | 22 mm | 7.0 Fr | 55 cm |
CR1088 | 22 mm | 8.5 Fr | 55 cm |
CR1089 | 22 mm | 6.5 Fr | 90 cm |
CR1090 | 22 mm | 7.0 Fr | 90 cm |
CR1091 | 22 mm | 8.5 Fr | 90 cm |
