InWIRE
Neurovascular
InWIREⓇ Guidewires are guidewires used for diagnostic or intervention device insertion and recanalization in Neurovascular and peripheral vessels, to access and traverse the lesion at a target lesion.
Superior Progressability Durable progression possible even in the most difficult lesions
- Easy steerability.
- Flat,malleable tip
- Hydrophilic polymer coating
- Radio-opeque tip
- In the distally tapering structure
- Torque Capability
Inwire Guide Wire products are for general intravascular use in neurovascular and peripheral vessels. Guidewires can be guided to facilitate the insertion of diagnostic and therapeutic catheters. It is available in 0.010”, 0.012”, 0.014”, and 0.018” diameters and is available in a variety of lengths and configurations. All models have a flat, malleable distal tip. The distal 2-3 cm portion of the tip is radiopaque.
Detailed specifications
InWIREⓇ Guidewires are a family of steerable guidewires with a formable tip, available in straight and preformed versions. Guidewires are compatible with existing microcatheters used in general procedures such as those used in the endovascular diagnosis and neurovascular disease treatment. The distal portion of the guidewire tip is radiopaque.
- Easy steerability
- Flat, malleable tip
- Hydrophilic polymer coating
- Radio-opaque tip
- In the distally tapering structure
- Torque Capability
Excellent Torque Capability
Elastic tip and integrated design for the quick delivery to the target vein
Allows 1:1 torque response
Hydrophilic Coating
Provides a durable and smooth progression possible even with curved veins
The outer diameters of the guide wires are listed in the table below.
Control
Nitinol construction offers a soft, atraumatic tip while maximizing push/pull control and torque response.
The lubricious hydrophilic coating allows smooth advancement of the guidewire within the vasculature and microcatheter
Excellent tip shape ability and shape retention design promotes controlled steerability
Durability
The proprietary hydrophilic coating offers exceptional integrity and durability
Kink-resistant distal nitinol core maintains its shape throughout the procedure, even though the most tortuous vessels
Versatility
Simplifies catheter exchange, intra-procedurally, reducing time and cost.
Superior Progressability Durable
progression possible
even in the most difficult lesions
- Easy steerability.
- Flat, malleable tip
- Hydrophilic polymer coating
- Radio-opaque tip
- In the distally tapering structure
-
Torque Capability
Order Number |
Description |
Total Lenght |
Hydrophilic Lenght |
Proximal Diameter |
Distal Diameter |
|
Soft |
300 cm |
30 cm |
0,012” |
0,010” |
|
Soft |
300 cm |
30 cm |
0,014” |
0,012” |
|
Soft |
260 cm |
30 cm |
0,018” |
0,016” |
