AnkaCATH
Distal Access Catheters
Intracranial Distal Access Catheter is designed for distal placement into the neurovasculature, providing intracranial support and a wide range of device compatibility.
Usable length | 90 cm, 120 cm | |
Tip Shape | Straight tip | |
Catheter Profile Proximal | 4F, 5F, 6F | |
Catheter Inner Diameter | 0.071” - 0.075” | |
Radiopaque marker | 1mm located at 2mm from the tip | |
Guidewire compatibility | Maximum diameter 0.035" | |
Coating | Hydrophilic | |
Structure of the Catheter | PE/PEBAX |
The AncaCath Catheter is a braided catheter of variable stiffness with a large non-conical lumen that provides intravascular passage of interventional devices. The distal segment is flexible for navigation within the distal vasculature. The catheter has an outer hydrophilic coating that reduces friction during the manipulation of the vessel. The slippery PTFE-lined inner lumen is designed to facilitate the movement of guide wires and other devices. A Luer connection at the tip of the catheter hub can be used to attach accessories. To aid visualization under fluoroscopy, the distal portion of the catheter is radiopaque and the distal end is distinguishable by a radiopaque marking.
Detailed specifications
Intracranial Distal Access Catheter is designed for distal placement into the neurovasculature, providing intracranial support and a wide range of device compatibility.
Small Pass Profile and Tapered Tip
Provides continuous guide wire-catheter passage for high support and successful lesion passage.
High bending resistance with excellent torque control and optimum push through from proximal shaft to the distal end
The rounded tip and flexible distal zone on the Distal Access Catheter are designed for confident advancement into fragile distal vessels.
The design of Distal Access Catheter is designed for closer placement to the treatment site. Focus on the intervention, not access challenges.
ADVANTAGES
Proximal shaft engineered for support throughout aortic arch
Excellent trackability
The 15cm distal flexible zone combined with a highly supportive proximal shaft for pushability leads to the smooth tracking design.
Gain stable distal support without sacrificing trackability
Image of Atraumatic access
Atraumatic Access
Usable length | 90 cm, 120 cm | |
Tip Shape | Straight tip | |
Catheter Profile Proximal | 4F, 5F, 6F | |
Catheter Inner Diameter | 0.071” - 0.075” | |
Radiopaque marker | 1mm located at 2mm from the tip | |
Guidewire compatibility | Maximum diameter 0.035" | |
Coating | Hydrophilic | |
Structure of the Catheter | PE/PEBAX |
Order Number | Device inner diameter | Working Length | Design | Surface | Inner Diameter | Shape |
NR1179 | 5.0 Fr | 90 cm | Braided | Hydrophilic | 0.055" | Straight |
NR1162 | 5.0 Fr | 120 cm | Braided | Hydrophilic | 0.055" | Straight |
NR1163 | 6.0 Fr | 120 cm | Braided | Hydrophilic | 0.071” | Straight |
